816659-B21-RFB Hewlett Packard Enterprise Intel Xeon E7-8891 v4, 60M Cache, 2.8 GHz, 9.6 GT/s QPI, 1P









816659-B21-RFB Hewlett Packard Enterprise Intel Xeon E7-8891 v4 60M Cache 2.8 GHz 9.6 GT/s QPI 1P









Intel Xeon E7-8891 v4 60M Cache 2,8 GHz 9,6 GT/s QPI 1P Opzioni accessori servizi e supporto per tutti i prodotti HP e Compaq.









Caratteristiche CPU configuration (max) 8 Embedded options available No Execute Disable Bit Yes Idle States Yes Market segment Server Maximum number of PCI Express lanes 32 PCI Express slots version 3.0 Physical Address Extension (PAE) 46 bit Physical Address Extension (PAE) Yes Scalability S8S Supported instruction sets AVX 2.0 Thermal Monitoring Technologies Yes Graphics On-board graphics card No Legal Information EU ECCN Code N/A UNSPSC Code (Icecat) 43201503 US ECCN Code 5A992 Memory ECC Yes Maximum internal memory supported by processor 3 TB Memory channels Quad-channel Memory clock speeds supported by processor 1066/1333/1600/1866 MHz Memory types supported by processor DDR3-SDRAM/DDR4-SDRAM Operational conditions Tcase 79 ?C Other Caratteristiche Compatibility DL580 GEN9 Package dimensions Gross Weight (Package kg) 0,2 kg Power Thermal Design Power (TDP) 165 Watt Processor Bus type QPI Component for Server/workstation Memory bandwidth supported by processor (max) 102 GB/s Number of QPI links 3 Processor base frequency 2,8 GHz Processor boost frequency 3,5 GHz Processor cache 60 MB Processor cache type L3 Processor cores 10 Processor family Intel Xeon E7 v4 Processor frequency 2,8 GHz Processor lithography 14 nm Processor model E7-8891V4 Processor operating modes 64-bit Processor series Intel Xeon E7-8800 v4 Processor socket LGA 2011 (Socket R) Processor threads 20 Stepping B0 System bus rate 9,6 GT/s Thermal Design Power (TDP) 165 Watt Processor special Caratteristiche Enhanced Intel SpeedStep Technology Yes Intel 64 Yes Intel Instruction Replay Technology No Intel Trusted Execution Technology Yes Intel TSX-NI Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel? AES New Instructions (Intel? AES-NI) Yes Intel? Hyper Threading Technology (Intel? HT Technology) Yes Intel? OS Guard Yes Intel? Secure Key Yes Intel? Turbo Boost Technology 2.0 Product dimensions Net Weight (Product kg) 0,1 kg ^ Brand Name Hewlett Packard Enterprise * 1 Anno(i) Categorie Categoria principale Parti per Server Computer e Stampanti Sottocategoria Server & Computer Sottocategoria Componenti di sistema Sottocategoria CPU
