BX8071512400 Intel Boxed Intel® Core™ i5-12400 Processor (18M Cache, up to 4.40 GHz) FC-LGA16A









BX8071512400 Intel Boxed Intel? Core? i5-12400 Processor (18M Cache up to 4.40 GHz) FC-LGA16A

















Caratteristiche Commodity Classification Automated Tracking System (CCATS) G167599 CPU configuration (max) 1 Direct Media Interface (DMI) Revision 4.0 Embedded options available No Execute Disable Bit Yes Export Control Classification Number (ECCN) 5A992CN3 Idle States Yes Market segment Desktop Maximum number of PCI Express lanes 20 PCI Express configurations 1x16+1x4/2x8+1x4 PCI Express slots version 4.0/5.0 Scalability 1S Supported instruction sets AVX 2.0/SSE4.1/SSE4.2 Thermal Monitoring Technologies Yes Use conditions PC/Client/Tablet Graphics Discrete graphics card No Discrete graphics card model Not available Multi-Format Codec Engines 1 Number of displays supported (on-board graphics) 4 Number of execution units 24 On-board graphics card Yes On-board graphics card base frequency 300 MHz On-board graphics card DirectX version 12.0 On-board graphics card dynamic frequency (max) 1450 MHz On-board graphics card maximum resolution (DisplayPort) 7680 x 4320 Pixels On-board graphics card maximum resolution (eDP - Integrated Flat Panel) 5120 x 3200 Pixels On-board graphics card maximum resolution (HDMI) 4096 x 2160 Pixels On-board graphics card model Intel UHD Graphics 730 On-board graphics card OpenGL version 4.5 On-board graphics card outputs supported DisplayPort 1.4a/Embedded DisplayPort (eDP) 1.4b/HDMI 2.1 On-board graphics card refresh rate at maximum resolution (DisplayPort) 60 Hz On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) 120 Hz On-board graphics card refresh rate at maximum resolution (HDMI) 60 Hz Legal Information UNSPSC Code (Icecat) 43201503 Logistics data Harmonized System (HS) code 85423119 Memory Maximum internal memory supported by processor 128 GB Memory bandwidth (max) 76,8 GB/s Memory channels Dual-channel Memory types supported by processor DDR4-SDRAM/DDR5-SDRAM Non-ECC Yes Operational conditions Tjunction 100 ?C Other Caratteristiche Graphics output eDP 1.4b DP 1.4a HDMI 2.1 Maximum internal memory 128 GB Package dimensions Gross Weight (Package kg) 0,46 kg Processor Box Yes Bus type DMI4 Cooler included Yes Maximum number of DMI lanes 8 Maximum turbo power 117 Watt Memory bandwidth supported by processor (max) 76,8 GB/s Performance cores 6 Performance-core base frequency 2,5 GHz Performance-core boost frequency 4,4 GHz Processor ARK ID 134586 Processor base power 65 Watt Processor boost frequency 4,4 GHz Processor cache 18 MB Processor cache type Smart Cache Processor codename Alder Lake Processor cores 6 Processor family Intel? Core? i5 Processor generation 12th gen Intel? Core? i5 Processor manufacturer Intel Processor model i5-12400 Processor operating modes 64-bit Processor socket LGA 1700 Processor threads 12 Processor special Caratteristiche Enhanced Intel SpeedStep Technology Yes Intel 64 Yes Intel Turbo Boost Max Technology 3.0 No Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel? AES New Instructions (Intel? AES-NI) Yes Intel? Boot Guard Yes Intel? Clear Video HD Technology (Intel? CVT HD) Yes Intel? Control-flow Enforcement Technology (CET) Yes Intel? Deep Learning Boost (Intel? DL Boost) on CPU Yes Intel? Gaussian & Neural Accelerator (Intel? GNA) 3.0 Yes Intel? Hyper Threading Technology (Intel? HT Technology) Yes Intel? Optane? Memory Ready Yes Intel? OS Guard Yes Intel? Quick Sync Video Technology Yes Intel? Secure Key Yes Intel? Speed Shift Technology Yes Intel? Standard Manageability (ISM) Yes Intel? Thread Director No Intel? Threat Detection Technology (TDT) Yes Intel? Turbo Boost Technology 2.0 Intel? Volume Management Device (VMD) Yes Product dimensions Net Weight (Product kg) 0,4 kg Product Depth 12,1 cm Product Height 7,7 cm Product Width 10,6 cm Technical details Launch date Q1'22 OpenCL version 2.1 Status Launched Target market Gaming ^ Brand Name Intel * 1 Anno(i) Weight & dimensions Processor package size 45 x 37.5 mm Categorie Categoria principale Parti per Server Computer e Stampanti Sottocategoria Server & Computer Sottocategoria Componenti di sistema Sottocategoria CPU
